Machine Name : Vertical Foam Cutting Machine
Description
Vertical Foam Cutting Machine is a practical table model for the vertical cutting of foam blocks. The table running on ball bearings. It has a retaining gib mounted in the front and is equipped with a movable vertical table fence. The table fence is movable from side to side by means of a ratchet. It can be moved in increments of from this arrangement assures fast and accurate repeat ability of cut. Foam block side cutting and trimming machine.
Introduction
Vertical foam cutting machines are used in the foam industries for the purpose of cutting the large foam blocks into desired dimensions, pieces and slices. For the purpose of trimming the slides of polyurethane blocks, the use of the vertical foam cutting machinery is recommended. The cutting height of the vertical foam cutting machines ranges from 600mm to 1500mm.
Introduction
In addition to this, the cutting length of this machine ranges from 1 ft to 7 ft., so based on the precise needs and demands provided by the patrons. Power required for systematic operation of the vertical foam cutting machinery consists of one horse power to 3 horse power.
Introduction
The size of the cutting blade used in the machinery ranges depends on the size of machine Space required by the machinery ranges depend on the size of machine based on the model of the machinery used.
Introduction
The inside blade used in the vertical foam cutting machinery ranges from based on the model of the vertical foam cutting machinery. In addition to this, the outside blade used in the vertical foam cutting machinery ranges from based on the model of the vertical foam cutting machinery.
Introduction
We are the leading manufacturer of vertical foam cutting machine in India and have installed about hundred of machines all over India. We have thousand of satisfied customers.
Machine Technical Data
| Table size (Blade outside size) | L: 2125mm × W: 2125mm. |
|---|---|
| Table size(Blade inside size) | L: 2125mm × W: 1200mm. |
| Cutting Material Support Side Wall | L: 2125mm × H: 600mm. |
| Maximum Cutting Height : | 1500mm. |
| Aluminium table top | |
| Manual Brake for the table for fast stopping. | |
| Upper and lower blade guidance. | |
| Machine Maximum Cutting Product Size(Blade 's Outside Size): | L:2000mm ×W: 2000mm H: ×1500 mm. |
| Machine Maximum Cutting Product Size(Blade 's Inside Size): | L:1200mm × W: 2000mm × H: 1500mm |
| Cutting Variation: | 0.5mm(+-) |
| Cutting Variation depend on the L,W,H and density of the material. | |
| Total Power Consumption: | 3 H.P. |
| Machine Operator: | 2 persons |
| Machine Installation Space: | L: 16ft. × W: 14ft. × H: 9ft. |
